High Sensitive External Internal Sensors TPMS Tire Pressure Monitoring System - TPMS - Shenzhen Xianghan Technology Co., Ltd.

High Sensitive External Internal Sensors TPMS Tire Pressure Monitoring System

High Sensitive External Internal Sensors TPMS Tire Pressure Monitoring System

1.Use solar energy to get electricity,with 4 internal or external sensors.

2.LCD pannel,with extra Micro USB port for charging.

3.Light weight design for sensor, no need to adjust to be balance when the tire moving.

4.Real-time Monitor the tempreature and pressure with high degree accuracy

5.Save fuel,foresee air leakage,reduce tire wearout,balance tire pressure,ensure safety driving.

  • Product introduction

Monitor specification

Sensor specification

Operating voltage

3.7-5V

Battery life

3-5 years

Storage temperature

-30°C-90°C

Storage temperature

-30°C-90°C

Working temperature

-30°C-85°C

Working temperature

-30°C-85°C

Emission frequency

433.92MHz±50KHz

Operating voltage

2.1-3.6V

Signal sensitivity

-90dbm

Transmitted power

10dBm

Display mode

LCD Color display

Pressure resolution

±0.1Bar

Working pressure

0-99Psi

Pressure range

0-7.0Bar

Bright operating current

6mA

Waterproof grade

IP67

Black operating current

4mA

Lithium battery

CR1632


1.Use solar energy to get electricity,with 4 internal or external sensors.

2.LCD pannel,with extra Micro USB port for charging.

3.Light weight design for sensor,no need to adjust to be balance when the tire moving.

4.Real-time Monitor the tempreature and pressure with high degree accuracy

5.Save fuel,foresee air leakage,reduce tire wearout,balance tire pressure,ensure safety driving.

6.RF wireless technology,can auto-alarm,when tire pressure and temperature is abnormal.

7.With two pressure unit"PSI,BAR " and two temperature unit"℃,℉" for option.

8.Sensor waterproof grade: IP67.

9..With Infineon Chip and RENATA anti-explosion battery.
