Motorcycle Bluetooth TPMS Tire Pressure Monitoring System TPMS
Thanks for choosing our BLE TPMS product which is designed for smart cellphones and supports cellphone with Bluetooth 4.0 or above.Once BLE tire sensor installed in wheel, tire pressure and temperature can be displayed in cellphone with APP. During travel, tire pressure and temperature displayed in real time and send alert when statistics' abnormal. For your safety, please read manual before using, thank you!
Motorcycle Bluetooth TPMS Tire Pressure Monitoring System TPMS
Thanks for choosing our BLE TPMS product which is designed for smart cellphones and supports cellphone with Bluetooth 4.0 or above.Once BLE tire sensor installed in wheel, tire pressure and temperature can be displayed in cellphone with APP. During travel, tire pressure and temperature displayed in real time and send alert when statistics' abnormal. For your safety, please read manual before using, thank you!
- Product introduction
| Sensor Parameter： |
| Processor | MCU/S08 |
| Kernel | ARM MO |
| Battery life | 24 months |
| Operating voltage | 3V |
| RF transmit frequency | 2.4GHz |
| Storage temperature | -30°C-90°C |
| Working temperature | -30°C-85°C |
| Temperature resolution | ±2°C(25°C) |
| Battery capacity | 140mA |
| Pressure resolution | ±10kpa |
| Waterproof grade | IP67 |
| Transmitted power | ≤10dBm |
| Transmit frequency | 433.92MHz |
| Weight | ≤8.0g |
| Size | 21mm*17mm |
| Lithium battery | CR1632(Model) |
